The CAVIUS Smart Remote is part of our Wireless Family range. This unique device will provide you with the ability to test and hush your smoke and heat alarms without having to physically touch the alarms themselves.

Once either a CAVIUS Wireless Family smoke or heat alarm activates, the Smart Remote will strobe and vibrate as an additional measure to provide extra warning of any potential fire in your home.

The Smart Remote must be within 4 metres and plain line of sight to hush or test an alarm. Can only be used with CAVIUS Wireless Family alarms.

Product Code: 9002 CAVSR

• ‍STROBES AND VIBRATES once a CAVIUS Wireless Family smoke or heat alarm is activated
• ‍TEST AND HUSH Your Wireless Family smoke or heat alarm with the remote
• ‍BUILT IN LED TORCH for everyday use or if the need to evacuate
• ‍MAGNETIC WALL BRACKET for convenient placement
• ‍USE AS SYSTEM MASTER when setting up your CAVIUS Wireless Family alarm system
• LOW BATTERY WARNING sounds with a 30 day low battery warning
• ‍CONNECTS with CAVIUS Wireless Family Mains Powered Smoke Alarm, Wireless Family 10 Year Smoke Alarm, Wireless Family 5 Year Smoke Alarm and Wireless Family 5 Year Thermal Heat Alarm

• BATTERY: 3 x AAA Duracell batteries (replaceable)
• RANGE: 4m (using test or hush function), 100m interconnection with other devices
• INTERCONNECTED RADIO FREQUENCY: 926.365 MHz
• OPERATING TEMPERATURE OF FUNCTION: +4ºC to +38ºC
• OPERATING HUMIDITY: Up to 90% RH non-condensing
• DIMENSIONS: 140mm (length)
• APPROVALS: CE, EN60065, EN50130 EMC, AS4268 RF demands, Reach

The CAVIUS Relay Interface connects to the CAVIUS Wireless Family alarms and integrates them to third-party external products. The 9005 CAVRI Relay provides a set of Normally Closed (NC) and Normally Open (NO) change over contacts. This enables CAVIUS smoke and heat alarms to trigger auxiliary devices such as security alarm panels, fire alarm panels, home automation systems, Telecare Systems, strobe lights, sounders, activate emergency lights, shut down air conditioners or release magnetic door holders.

This product allows third party devices such as sprinkler flow switches or fire panels to be connected via the relay switch inputs, to trigger the CAVIUS alarms to sound, when activated.

Product Code: 9005 CAVRI

• REPLAY SWTICH (NO/NC) activities when the CAVIUS Wireless Family alarms detect a fire event‍
• TRIGGER IMPUT for two-way activation (latched or pulsed) Volt-free:3v DC output with return, Voltage in: 3v – 30v
• BATTERY BACK UP Duracell Lithium battery (replaceable)
• OUTPUT REPLY: 250v AC @ 5 amps or 30v DC @ 5 amps
• VISUAL INDICATOR Green LED indicating mains power supply‍
• NEW RF TECHNOLOGY with the ability to connect up to 32 Wireless Family alarms
• ‍INTELLIGENT TEST BUTTON confirms the alarm is functioning correctly
• ‍10 MINUTE hush button
• ‍30 DAY low battery alert
• ‍EASY INSTALLATION with the unique smart-clip ceiling mechanism
• ‍AS3786:2014 certified, NZ Building Code, RTA and NZS 4514:2021 compliant
• ‍POWER ON Green ‘Power On’ LED light as a visible indicator of mains power supply CA
• ACCESSORY OPTION Ability to work as a lamp hook, to avoid an extra spot on the ceiling
• ‍CONNECTS with CAVIUS Wireless Family Mains Powered Smoke Alarm, Wireless Family Smart remote, Wireless Family 5 Year Smoke Alarm and Wireless Family Thermal Heat Alarm

The SmartSense SmartHub plugs directly into your internet router and connects your CAVIUS Wireless Family devices to the CAVIUS App. This allows you to receive alerts to your smartphone or tablet when your smoke or heat alarm is activating, it will also provide the details of which alarm is activating. You can also test your alarms, complete regular fire drills, receive low battery status and connect with third party apps, on their phone anyway (with internet).

In addition, you can have multiple accounts for different properties – like monitoring the smoke alarms of your elderly family, holiday home or your rental property.

The pack contains the SmartHub, power supply, user guide and RJ45 connection cable.

Product Code: 02200

• ALARM IDENTIFICATION: Allocate a unique name to each alarm i.e. ‘Jacks Bedroom’.
• ACTIVATED ALARM NOTIFICATION:  Receive a notification, via the app, when an alarm has been activated. The app will indicate which alarm has been activated.
• LOW BATTERY ALERT: Receive a notification, via the app, when an alarm’s battery is low and requires replacing.
• CONNECTION NOTIFICATION: The alarms will send a ‘pulse’ every 24 hours to indicate they are connected to the SmartHub. If the SmartHub does not receive the pulse signal or there is an outage with the internet connection – the app will send a notification to the user.
• INTERCONNECTION TEST: Run an interconnection test to check all alarms are in range and connected to each other.
• FIRE DRILL TEST: Run a Fire Drill within the system, this will activate all the alarms and replicate the alarms response to a real fire event.
• UNLIMITED USERS: Add unlimited users onto one system. There are two levels of users; Administration (full access to the system) User (will only receive notifications via the app)
• THIRD PARTY APPLICATIONS: Works with Google Assistant and ability to intergrade with IFTTT.

Fitted with CAVIUS CORE technology, the Wireless Family, Mains powered Photoelectric Smoke Alarm is the smallest and most aesthetically pleasing 240v hardwired interconnected smoke alarm in New Zealand.

The CAVIUS Wireless Family range of smoke alarms interconnect with each other using, built in, innovative Radio Frequency technology, so that when one alarm activates, they all sound. The range between alarms will depend on the building materials and should be tested in each individual case. Setting up and interconnecting your alarms is simple and takes less than a minute.

CAVIUS alarms have been designed and manufactured to cope with the harsh environments, they include two levels of mesh screening to minimise insect and dust contamination – alleviating the potential for nuisance alarms. They have an easy to access 10-minute hush button (or the alarms can be silenced using the CAVIUS Smart Remote).

The AS3786:2014 certified alarm performs a chamber sensitivity calibration every 365 days allowing them to retain the optimal safety detection during its lifetime and comes with a 10-year warranty.

Photoelectric Smoke Alarms should be installed in all bedrooms, lounges and hallways. For other areas where a smoke alarm cannot be installed (such as the kitchen, garage, workshop, or laundry) a Wireless Family Heat Alarm is recommended.

NB: Mains Powered or hard wired smoke alarms need to be installed by a professional or registered electrician. There is a recess kit available for this product 2901RK

Product Code: 2203 CAVMP

• NZ BUILDING CODE COMPLIANT
• ‍10 YEAR BATTERY BACK UP Duracell Lithium (replaceable)
• ‍NEW RF TECHNOLOGY with the ability to connect up to 32 Wireless Family alarms
• ‍INTELLIGENT TEST BUTTON confirms the alarm is functioning correctly
• ‍10 MINUTE hush button
• ‍30 DAY low battery alert
• ‍EASY INSTALLATION with the unique smart-clip ceiling mechanism
• ‍AS3786:2014 certified, NZ Building Code, RTA and NZS 4514:2021 compliant
• ‍POWER ON Green ‘Power On’ LED light as a visible indicator of mains power supply CA
• ACCESSORY OPTION Ability to work as a lamp hook, to avoid an extra spot on the ceiling
• ‍CONNECTS with CAVIUS Wireless Family Mains Powered Smoke Alarm, Wireless Family Smart remote, Wireless Family 5 Year Smoke Alarm and Wireless Family Thermal Heat Alarm

• ‍SENSOR TYPE: Photoelectric/Optical smoke detection
• ‍BATTERY: Duracell Lithium CR2 3V
• ‍INTERCONNECTED RADIO FREQUENCY: 926.365 MHz
• ‍RANGE: Maximum 100m in plain line of sight
• ‍CHAMBER: Optical reading in the chamber every 8 seconds
• ‍VISUAL INDICATOR: Activated alarm’s LED will flash
• ‍SOUND LEVEL: 85db at 3 meters
• ‍OPTIMAL TEMPERATURE OF FUNCTION: +4ºC to +38ºC
• ‍MAXIMUM HUMIDITY: +95% Rh non-condensing
• ‍CERTIFICATIONS: • AS3786:2014 • NF292 • RoHs • Reach • ActivFire®

AVAILABLE FROM OCTOBER 2024

Fitted with CAVIUS CORE technology, the Wireless Family, 10 Year Photoelectric Smoke Alarm is the smallest and most aesthetically pleasing interconnected alarm in New Zealand.

The alarm comes with two installation options; either flush mounted (38mm profile) or recessed (19mm profile) to give you a low-profile and sleek look.

The CAVIUS Wireless Family range of smoke alarms interconnect with each other using, built in, innovative Radio Frequency technology, so that when one alarm activates, they all sound. The range between alarms will depend on the building materials and should be tested in each individual case.

The battery-operated CAVIUS Wireless Family alarms require no wiring or internet connection. Setting up and interconnecting your alarms is simple and takes less than a minute.

CAVIUS alarms have been designed and manufactured to cope with the harsh environments, they include two levels of mesh screening to minimise insect and dust contamination – alleviating the potential for nuisance alarms. They have an easy to access 10-minute hush button (or the alarms can be silenced using the CAVIUS Smart Remote).

The AS3786:2014 certified alarm performs a chamber sensitivity calibration every 365 days allowing them to retain the optimal safety detection during its lifetime and comes with a 10-year warranty.

Photoelectric Smoke Alarms should be installed in all bedrooms, lounges and hallways. For other areas where a smoke alarm cannot be installed (such as the kitchen, garage, workshop, or laundry) a Wireless Family Heat Alarm is recommended.

Product Code: 2117 CAV10WF

• ‍10 YEAR LONG-LIFE Huiderui Lithium CR123A 3V, 2800mAh (sealed)
• ‍SOUND LEVEL 85db at 3 meters
• ‍NEW RF TECHNOLOGY allows connection to up to 32 Wireless Family alarms
• ‍INTELLIGENT test confirms the alarm is functioning correctly
• ‍10 MINUTE hush button
• ‍30 DAY low battery alert
• ‍EASY INSTALLATION with the unique smart-clip ceiling mechanism
• ‍CEILING OR WALL INSTALLATION – There are two installation options available – recessed and flush mount. Profile: 19mm (Recessed) 36mm (Flush)
• ‍AS3786:2014 certified, NZ Building Code and NZS 4514:2021 compliant
• ‍CONNECTS with CAVIUS Wireless Family Mains Powered Smoke Alarm, Wireless Family Smart remote, Wireless Family 5 Year Smoke Alarm and Wireless Family Thermal Heat Alarm

• ‍SENSOR TYPE: Photoelectric/Optical smoke detection
• ‍BATTERY: 2 x Huiderui Lithium CR123A 3V, 2800mAh
• ‍INTERCONNECTED RADIO FREQUENCY: 926.365 MHz
• ‍RANGE: Maximum 100m in plain line of sight
• ‍CHAMBER: Optical reading in the chamber every 8 seconds
• ‍VISUAL INDICATOR: Activated alarm’s LED will flash
• ‍OPTIMAL TEMPERATURE OF FUNCTION: +4ºC to +38ºC
• ‍MAXIMUM HUMIDITY: +95% Rh non-condensing
• ‍DIMENSIONS: 78mm diameter
• ‍CERTIFICATIONS: • AS3786:2014 • NF292 • RoHs • Reach • ActivFire®

Fitted with CAVIUS CORE technology, the Wireless Family, 10 Year Photoelectric Smoke Alarm is the smallest and most aesthetically pleasing interconnected alarm in New Zealand.

The alarm comes with two installation options; either flush mounted (38mm profile) or recessed (19mm profile) to give you a low-profile and sleek look.

The CAVIUS Wireless Family range of smoke alarms interconnect with each other using, built in, innovative Radio Frequency technology, so that when one alarm activates, they all sound. The range between alarms will depend on the building materials and should be tested in each individual case.

The battery-operated CAVIUS Wireless Family alarms require no wiring or internet connection. Setting up and interconnecting your alarms is simple and takes less than a minute.

CAVIUS alarms have been designed and manufactured to cope with the harsh environments, they include two levels of mesh screening to minimise insect and dust contamination – alleviating the potential for nuisance alarms. They have an easy to access 10-minute hush button (or the alarms can be silenced using the CAVIUS Smart Remote).

The AS3786:2014 certified alarm performs a chamber sensitivity calibration every 365 days allowing them to retain the optimal safety detection during its lifetime and comes with a 10-year warranty.

Photoelectric Smoke Alarms should be installed in all bedrooms, lounges and hallways. For other areas where a smoke alarm cannot be installed (such as the kitchen, garage, workshop, or laundry) a Wireless Family Heat Alarm is recommended.

Product Code: 2107 CAV10WF

• ‍10 YEAR LONG-LIFE Huiderui Lithium CR123A 3V, 2800mAh (sealed)
• ‍SOUND LEVEL 85db at 3 meters
• ‍NEW RF TECHNOLOGY allows connection to up to 32 Wireless Family alarms
• ‍INTELLIGENT test confirms the alarm is functioning correctly
• ‍10 MINUTE hush button
• ‍30 DAY low battery alert
• ‍EASY INSTALLATION with the unique smart-clip ceiling mechanism
• ‍CEILING OR WALL INSTALLATION – There are two installation options available – recessed and flush mount. Profile: 19mm (Recessed) 36mm (Flush)
• ‍AS3786:2014 certified, NZ Building Code and NZS 4514:2021 compliant
• ‍CONNECTS with CAVIUS Wireless Family Mains Powered Smoke Alarm, Wireless Family Smart remote, Wireless Family 5 Year Smoke Alarm and Wireless Family Thermal Heat Alarm

• ‍SENSOR TYPE: Photoelectric/Optical smoke detection
• ‍BATTERY: 2 x Huiderui Lithium CR123A 3V, 2800mAh
• ‍INTERCONNECTED RADIO FREQUENCY: 926.365 MHz
• ‍RANGE: Maximum 100m in plain line of sight
• ‍CHAMBER: Optical reading in the chamber every 8 seconds
• ‍VISUAL INDICATOR: Activated alarm’s LED will flash
• ‍OPTIMAL TEMPERATURE OF FUNCTION: +4ºC to +38ºC
• ‍MAXIMUM HUMIDITY: +95% Rh non-condensing
• ‍DIMENSIONS: 78mm diameter
• ‍CERTIFICATIONS: • AS3786:2014 • NF292 • RoHs • Reach • ActivFire®

The CAVIUS 10-year Thermal Heat Alarm detects fast, flaming fires in kitchens, garages, workshops and laundries, and keeps you and your family safer.

Using state-of-the-art Danish technology, the Thermal Heat Alarm monitors changes in ambient room temperature and sounds if there is a rapid, constant temperature increase. It is also the world’s smallest heat alarm at just 40mm.

If rapid and constant increase of temperature occurs or ambient  temperature reaches >58°C, the alarm will sound.

Product Code: 3004 CAVTH10

• ‍10 YEAR LONG-LIFE Duracell Lithium Battery (sealed)
• ‍SOUND LEVEL 85db at 3 meters
• ‍INTELLIGENT TEST BUTTON ensures both the thermistor and software are functioning
• ‍10-MINUTE hush button
• ‍30-DAY low battery alert
• ‍EASY INSTALLATION with the unique smart-clip ceiling mechanism
• ‍CEILING OR WALL INSTALLATION There are two installation options available – recessed and flush mount. Profile: 19mm (Recessed Ceiling Only) 44mm (Flush)
• ‍TESTED TO EN54-5

• ‍SENSOR TYPE: Thermistor Heat detection
• ‍BATTERY: Duracell Lithium Battery CR123A 3V, 1600mAh (sealed)
• ‍OPTIMAL TEMPERATURE OF FUNCTION: +4ºC to +38ºC
• ‍MAXIMUM HUMIDITY: +95% Rh non-condensing
• ‍DIMENSIONS: 40mm diameter
• ‍CERTIFICATIONS: CE EN60065 • EN54-5 • RoHs • Reach

The 40mm CAVIUS 10-year Photoelectric Smoke Alarm is the world’s smallest smoke alarm, so it’s hardly seen – even in the centre of the room which is exactly where a smoke alarm needs to be.

Danish by design, the aesthetically pleasing CAVIUS smoke alarms are not only the world’s smallest, they also contain advanced technology and intelligent features.

The alarm will make an optical reading every 8 seconds ensuring it is always ‘on the lookout’ for smoke.

When you press a CAVIUS smoke alarm test button, you are not only testing its audible output, this function is also testing the optical light and visible indicators to ensure the smoke alarm is working as it should.

Photoelectric Smoke Alarms should be installed in all bedrooms, lounges and hallways. For other areas where a smoke alarm cannot be installed (such as the kitchen, garage, workshop, or laundry) a Thermal Heat Alarm is recommended.

Product Code: 2008 CAV10

• 10 YEAR LONG-LIFE Duracell Lithium Battery (sealed)
• SOUND LEVEL 85db at 3 meters
• INTELLIGENT TEST BUTTON which tests audible output, optical light and visible indicators to ensure the smoke alarm is fully operational
• 10-MINUTE hush button
• 30-DAY low battery alert
• EASY INSTALLATION with the unique smart-clip ceiling mechanism
• CEILING OR WALL INSTALLATION There are two installation options available – recessed and flush mount. Profile: 19mm (Recessed Ceiling Only) 44mm (Flush)
• CERTIFICATION AS3786:2014 certified, New Zealand Building Code and RTA compliant.

• ‍SENSOR TYPE: Photoelectric/Optical smoke detection
• ‍BATTERY: Duracell Lithium CR123A 3V, 1600mAh (sealed)
• ‍OPTIMAL TEMPERATURE OF FUNCTION: +4ºC to +38ºC
• ‍MAXIMUM HUMIDITY: +95% Rh non-condensing
• ‍DIMENSIONS: 40mm diameter
• ‍CERTIFICATIONS: • AS3786:2014 • ActivFire® • NF292 • RoHs • Reach
